Crouzet: Subminiature Microswitches (V4D - 8327 Series)
With over 60 years’ experience in snap-action technology, Crouzet Switches offers a complete range of Microswitches for the highly demanding markets. The extensive choice consists of standard or customized Sub-subminiature, Subminiature, Miniature and Special microswitches, all conform to the most rigorous quality standards.
Our microswitches are characterized by a large range of switching ratings from 1 mA to 25 A, magnetic blowout versions for High DC ratings, sealed models, positive break versions, a wide range of operating temperatures, models for explosive atmospheres, long service life and wide variety of actuators, contact materials and fixing means.
Subminiature Microswitches – Standard
Flexible leaf snap-action mechanism with wiping contacts
ENEC and cURus approved up to +150°C
Housing material complying with IEC 60335-1 for unattended appliances: GWFI 850° C / GWIT 775° C
Mushroom-head button variant for lateral approach up to 45°
Choice of connections with symmetric and asymmetric pinning
Choice of pre-assembled actuators
Specifications
Approx body size (mm): 20x10x6
Rating (max): 12A/250Vac
Degree of protection: IP40
Operating temperature: -25°C/+150°C
Operating force (max): 1,5N
Differential travel (max): 0.15 mm
Overtravel (min): 0.5 mm
Mechanical life (cycles): 0.1 M
