Delta: PLC - Programmable Logic Controllers (AH500 Series) Programmable logic controller (PLC) is a control system using electronic operations. Its easy storing procedures, handy extending principles, functions of sequential/position control, timed counting and input/output control are widely applied to the field of industrial automation control.
Delta's DVP series programmable logic controllers offer high-speed, stable and highly reliable applications in all kinds of industrial automation machines. In addition to fast logic operation, bountiful instructions and multiple function cards, the cost-effective DVP-PLC also supports various communication protocols, connecting Delta's AC motor drive, servo, human machine interface and temperature controller through the industrial network in to a complete "Delta Solution" for all users. Highly integrated software ISPSoft: Graphical Interface with 5 programming languages Enhanced flexibility: Max. 100m between 2 local extension racks Improved maintainability: Hot-swapping function keeps the system running
Utilizes dual-core multi-tasking processor Excellent program execution speed: 0.3ms / 1k steps Max. I/O points: - DIO: Max. 4,352 points - AIO: Max. 544 channels - RIO: Max. 125,440 digital points / 3,920 analog channels Program capacity: Max. 256k steps Data register: Max. 64k words CPU built-in with fully isolated RS-232/422/485,Mini-USB, Ethernet, SD Card 1.0(compatible with the memory cards on the market) Abundant selection of AIO modules, DIO modules, temperature modules, network modules, pulse-train and DMCNET motion control modules
Large Scale Industrial Machines The AH500 supports excellent motion control functions including 3-axis linear interpolation, 2-axis arc interpolation, and 3-axis helical interpolation. In addition, the AH500 is capable of controlling up to 12 axes or 4 groups of 3-axis interpolation synchronously at 1ms through Delta's high speed DMCNET motion control network. The AH500 satisfies requirements for complex processing or precise motion control and is effective for applications such as building material processors, warp knitting machines and food packaging machines. The AH500 is a modular system controller designed for almost all types of high-level automation tasks. Its abundant selection of I/O modules and the flexible system structure provide the best solutions for all kinds of system integration requirements. Through remote I/O expandability, you can build up the AH500 main station as a central control system and allocate the remote I/O systems on different floors for HVAC applications, or in different processing stations for the paper-making industry. The AH500 not only fulfills the application requirements for industrial machines or devices, but it also provides total solutions for automation systems.
|
|
|
 |
|
 |
|
