Unitronics: Jazz® PLC+HMI ((JZ10-11 Series) An All-in-One controller that is as affordable as a “smart relay” — full-function PLC combined with a textual HMI and keyboard, with up to 40 onboard I/Os. Replace that “smart relay” with a real PLC—for the same low price.
The Jazz® series controllers are full-function Programmable Logic Controllers with onboard I/Os and a built-in Operator Panel. The Jazz® series’ are specifically designed to control small machines, and to perform simple-to-medium automation tasks. Compact and economical, they enable you to use a low-budget unit without compromising on features and technology.
The Jazz® offers the flexibility of Ladder programming (24K Ladder code, virtual), on-board I/O configurations (some models with direct temperature inputs), communication options such as GSM/SMS, Remote Access, and MODBUS networking. The HMI application enables you to design up to 60 text screens, using up to 64 HMI variables for the display of time, date, and real-time system data. Programming is as easy as it gets—build Ladder Logic control applications using click-and-drop elements…and create your HMI application in the same simple environment.
Our PLC/HMI integrated devices: Save our customers’ programming time, wiring, and cabinet space. Cut budget by reducing requirements for additional hardware Prevent you from wasting time setting up Panel-PLC communication
6 Digital Inputs including 2 inputs which can function as either high-speed counters, or as normal digital inputs 4 Transistor Outputs 2 Lines x 16 characters, STN LCD, LED backlight HMI Displays 24 VDC power supply
6 Digital inputs including 2 inputs which can function as either high-speed counters, or as normal digital inputs 2 Digital/Analog inputs 2 Analog inputs 7 Transistor Outputs 2 Lines x 16 characters, STN LCD, LED backlight HMI Displays 24 VDC power supply
3 Digital Inputs including 1 Input which can function as either high-speed counter, or as a normal digital input 3 Digital/Analog Inputs 3 PT1000/NI1000 Inputs 5 Relay Outputs 1 Transistor Output, including 1 HSO 2 Lines x 16 characters, STN LCD, LED backlight HMI Displays 24 VDC power supply
9 Digital Inputs including 1 Input which can function as either high-speed counter, or as a normal digital input 2 Digital/Analog Inputs 1 Thermocouple/PT100/Analog Input 5 Relay Outputs 2 Transistor Outputs, including 2 PWM 2 Lines x 16 characters, STN LCD, LED backlight HMI Displays 24 VDC power supply
9 Digital Inputs including 1 Input which can function as either high-speed counter, or as a normal digital input 2 Digital/Analog Inputs 2 Thermocouple/PT100/Analog Inputs 5 Relay Outputs 2 Transistor Outputs, including 2 PWM 2 Analog Outputs 2 Lines x 16 characters, STN LCD, LED backlight HMI Displays 24 VDC power supply
16 Digital inputs including 2 Inputs which can function as either high-speed counters, or as normal digital inputs 2 Digital/Analog inputs 2 Analog inputs 20 Transistor Outputs 2 Lines x 16 characters, STN LCD, LED backlight HMI Displays 24 VDC power supply

|
|
|
 |
|
 |
|
