AMP: NEMA 34 High Torque Step Motor With Encoder HT34-695D-YAA

The HT34-695 two-phase stepper motor is suitable for a wide range of motion control applications. The motor is optimized for use with high bus-voltage stepper drives such as the STAC5, STAC6 and STRAC series drives. The motor comes with an integral 10 ft shielded cable and is terminated with 8 motor leads plus 1 ground lead making it easy to connect the motor to the drive depending on the supply voltage being used. For 120 VAC applications the motor leads must be connected in parallel. For 220 VAC applications the motor leads must be connected in series.

UL Recognized

The single and double shaft versions of this motor are UL Recognized in the US and Canada, file no. E472271. The encoder and encoder cover are not included in the listing.

Product Features

• 2-phase hybrid step motor
• High torque design
• Standard NEMA 34 dimensions
• Integral 10 ft shielded cable w/ strain relief
• Single shaft version standard
• Double shaft version with encoder available
• Optimized for high bus voltage operation
