FANUC:18/180/180i-SB 3 SLOT STAND ALONE
BASIC UNIT
Part
Number: A02B-0297-B803
Product Series: A02B-0297
FEATURES:
The Fanuc 18/180i-SB series control units are divided into two types: the
LCD-mounted type and stand-alone type. LCD-mounted type control units have a
built-in display. Stand-alone type control units have a separate display unit. The
control unit is equipped with a fan motor. Air is fed into the bottom of the
unit and output from the fan motor mounted on the top of the unit. FANUC thus
recommends that the battery be replaced periodically, once a year, regardless
of whether a battery alarm is issued. The following two kinds of batteries can
be used.
•
Lithium battery built into the CNC control unit.
•
Two alkaline dry cells (size D) in the external battery case.
HIGHLIGHTS.
The control unit is equipped with a fan motor.
Air
is fed into the bottom of the unit and output from the fan motor mounted on the
top of the unit. Also, adequate service access space is required in front of
and at the topof
the unit so that printed circuit boards and the fan motor can be replacedeasily
if necessary. There is a spare connector located at the far end (at middle
height) on the right side of the control unit. This connector is used for
controller testing and other purposes. Therefore, connector is required..All
the stand–alone type control units of the Series 180i are designed to connect
an intelligent terminal by inserting an HSSB interface board into a mini slot.
These control units are the same as those of the Series 18i..
SPECIFICATIONS:
Servo
Drive is a solid-state semiconductor device with four layers of alternating N
and P-type material.
Servo
Drive is a larger set of devices with at least four layers of alternating N and
P-type material.
Servo
Drive can control a relatively large amount of power and voltage with a small
device.
DESCRIPTION:
Thick
copper baseplate, Insulated Type, Thick AL metal die and double stick bonding
FEATURES
& APPLICATIONS:
AC
Motor Control. Battery DC Power supplies. DC power supplies for control panels.
Contactless switches
