FANUC:16 i-A BASIC UNIT

Part Number: A02B-0236-C612
Product Series: A02B-0236

FEATURES:

The FANUC Series 16i/18i/21i-MODEL-A CNC has two FANUC I/O Link interface channels. These channels make it possible to increase the number of I/O points from 1024/1024 to 2048/2048. This chapter explains how to connect a 2-channel I/O Link connector adapter required in using the I/O Link 2-channel function. Using this function on the 16i/18i/21i-MODEL B mentioned above requires specifying the PMC-SB6/-SB7. This function cannot be used with the PMC on the loader control board.

Two channels' worth of I/O Link signals are allocated to the I/O Link connector (JD44A) of the Series 16i/18i/21i-MODEL B CNC.
