CODESYS Control for Linux ARM SL Article no. 2302000039

The CODESYS Control Linux ARM SL is an adapted CODESYS runtime system for Linux/ARM-based platforms. The performance of the runtime system is almost arbitrarily scalable via the hardware properties of the system.

To install the product on the Linux OS via the CODESYS Development System, use the the included CODESYS Deploy Tool plug-in. After each restart the runtime system will be started automatically. If no valid full license can be found, CODESYS Control runs for two hours without functional limitations before shut down.

After installing the runtime environment, the PLCnext controller can be programmed as a PLC with the CODESYS Development System.

Benefits

The runtime system supports numerous I/O interfaces, such as discrete inputs and outputs or fieldbus adapters, as well as integrated IEC 61131-3 protocol stacks. The fieldbuses are configured directly in the CODESYS Development System without using any additional tools.

Communication with the CODESYS Development System for programming and debugging of the IEC 61131-3 application

Execution of controller functions and generation of graphical user interfaces

Operation of I/O systems and fieldbuses

Performance

CODESYS Multicore is included as full version in the delivery of the runtime package.
